Lightweight. Reliable. Cost effective.
Designed for the S-61/Sea King series helicopters, AEM’s MCP02 Master Caution Panels are plug-and-play replacements for the original OEM units. Our one-piece display filter keeps the component clean, preventing moisture and other contaminants from getting into the front panel. The MCP02 features dual redundancy LED lighting with optional NVG and is tested and qualified to DO-160G. Refer to our product brochure for the complete list of certifications.
- Uses existing plugs and wiring for plug-and-play replacement
- No bulb replacement required due to LED display
- Optional NVIS-compliant lighting
- Master unit can operate with OEM auxiliary units
- Transport Canada Supplemental Type Certificate SH16-25
- FAA Supplemental Type Certificate SR03914NY
MCP02 Documents
| Title | Categories | Download |
|---|
| MCP02 Master Mechanical Specs | |
|---|---|
| Height | 4.81″ [122.2 mm] MAX |
| Width | 6.78″ [172.2 mm] MAX |
| Length | 1.83″ [46.9 mm] MAX (behind panel) |
| Weight | 1.75 lb [0.80 kg] MAX |
| MCP02 Auxiliary 1 & 2 Mechanical Specs | |
|---|---|
| Height | 3.01″ [76.5 mm] MAX |
| Width | 5.76″ [146.3 mm] MAX |
| Length | 1.67″ [42.4 mm] MAX (behind panel) |
| Weight | 1.25 lb [0.57 kg] MAX |
| MCP02 Chip Detect Mechanical Specs | |
|---|---|
| Height | 1.50″ [38.1 mm] MAX |
| Width | 5.76″ [146.3 mm] MAX |
| Length | 1.67″ [42.4 mm] MAX (behind panel) |
| Weight | 0.75 lb [0.34 kg] MAX |
